Setup SFTP Server And Users In Ubuntu Linux

In Linux, chroot stands for change root. It is a process of creating a jailed environment for a calling process (e.g., SFTP) to isolate it from the rest of the system.

SFTP (Secure Shell File Transfer Protocol) is a means of transferring files securely from a client to a server over a network.

Sometimes, you may want to grant SFTP access to allow users to upload files on your Linux server. However, this could pose a security risk to the entire file system.

To mitigate this risk, chroot is used. It changes the root directory of the user during an SFTP session, ensuring isolation from the main system.

Chrooted users cannot break the jail but can still run standard SFTP commands to manage their directories and files.

This is a step-by-step guide for creating an SFTP chroot environment on an Ubuntu 16.04 instance that locks users to their home directory while restricting shell access for security purposes.

Prerequisites

• A Linux server running Ubuntu 16.04.

• A non-root user with sudo privileges

Step 1: Creating an SFTP Group

To manage chrooted users, create a group using the groupadd command:

sudo groupadd sftpusers

Replace sftpusers with your preferred group name.

Step 2: Setting Up OpenSSH

SFTP operates over SSH and inherits its security features, including data encryption that prevents password sniffing and man-in-the-middle attacks.

OpenSSH reads configuration settings from /etc/ssh/sshd_config. Modify this file using a text editor such as nano:

sudo nano /etc/ssh/sshd_config

Locate the line:

#Subsystem sftp /usr/lib/openssh/sftp-server

And change it to:

Subsystem sftp internal-sftp

Add the following lines at the end of the file:

Match Group sftpusers
    ChrootDirectory %h
    X11Forwarding no
    AllowTcpForwarding no
    ForceCommand internal-sftp

Ensure to replace sftpusers with the group name you created.

Explanation of Configuration:

• Subsystem sftp internal-sftp: Configures the in-process SFTP server, simplifying chroot configurations.
• Match Group sftpusers: Applies the settings to users in the sftpusers group.
• ChrootDirectory %h: Restricts users to their home directory.
• X11Forwarding no: Disables X11 forwarding to limit access to graphical applications.
• AllowTcpForwarding no: Disables TCP forwarding to enhance security.
• ForceCommand internal-sftp: Ensures only the SFTP process runs upon login.

Restart the SSH daemon after making changes:

sudo service ssh restart

Step 3: Configuring User Accounts

Create and configure user accounts. For example, to create a user named jacob:

sudo adduser jacob

Follow the prompts to set the user password and details. By default, this command creates a home directory /home/jacob. Add the user to the sftpusers group:

sudo usermod -G sftpusers jacob

Change the ownership of the user’s home directory to root:

sudo chown root:root /home/jacob

Set the appropriate permissions:

sudo chmod 755 /home/jacob

Create subdirectories within the user’s home and assign ownership:

sudo mkdir /home/jacob/outbound
sudo chown jacob:jacob /home/jacob/outbound

sudo mkdir /home/jacob/inbound
sudo chown jacob:jacob /home/jacob/inbound
sudo chmod 700 /home/jacob/inbound

chmod 700 only allows jacob user to read and write and will not allow any other user to read.

Step 4: Testing the Configuration

Connect to your server using SFTP with the newly created user:

sftp jacob@<your-vps-ip>

Verify the connection by running the pwd command:

sftp> pwd
Remote working directory: /

Step 5: Confirming Shell Access Restriction

Attempt to connect via SSH with the restricted user credentials. If the setup is correct, shell access should be denied.

Congratulations! You have successfully created a chroot environment with SFTP access for your users.
